PLX Metrology / Laser Tracking Applications

Metrology

PLX Ball Mounted Hollow Retroreflectors™ (BMRs™) are used as targets for laser trackers and are the most accurate in the industry.

PLX offers both stainless steel and ceramic Ball BMR's. Our new Durable Ball Mounted Hollow Retroreflectors™ (DBMRs™) offer increased durability and are designed to work in demanding environments.

Laser trackers measure distances and coordinates to a very high degree of accuracy and precision. As a single surface invariant reflector, the BMRs provide great accuracy, together with a constant optical path difference. This is especially important because they allow accurate distance measurement without the need to account for refraction, a common problem when using solid prism type Retroreflectors.

The PLX Ball Mounted Hollow Retroreflectors™ are manufactured in three different diameters: 1 1/2", 7/8" and 1/2", and are available in two centering accuracies, .0005" and .0001".

The new DBMRs™ (Durable Ball Mounted Retroreflectors™) are available in 1.5” diameter and two centering options (0.0001” and 0.0005”), all are guaranteed to be compatible with all manufacturers’ laser tracking systems.

Beam Separator

Beam Separator

Separates one input beam with multiple wavelengths into 3 different outputs for metrology applications.

Monolithic scanning device

Monolithic scanning device

Designed to oscillate at a rate higher than 1KHz, while maintaining its stability and accuracy, this lightweight structure is balanced to reduce the moment of inertia about the pin axes.
